V68 Pro IPE VTOL Drone Motor

SKU: 0101DJ1193
1.5-6.5kg per rotor, Max thrust is up to 13.9kg per rotor.
2.unit motor weighs only 378g.

3.Designed for 15-20kg MTOW professional industrial VTOL fixed-wing UAS, with large-pitch VOTL CF propellers
$0.00 $179.00
Received successfully
Coupon Code
CONTINUE SHOPPING
    Please select the information you wantX
Quantity
-
+
  • V68 Pro IPE VTOL motor 230KV
  • V68 Pro IPE VTOL motor 230KV
  • V68 Pro IPE VTOL motor 230KV
  • V68 Pro IPE VTOL motor 230KV
  • Description
  • 230KV

Motor Data

Motor Model MAD V68 PRO IPE V1.0 Number of pole pairs 14
Stator Anticorrosive Varnished wire Degree 150°C
Motor Size D:72 × 43.5 mm Motor Balance 150°C
Degree of Protection IP35 Cable Length 80 mm 16# Awg(Black) silicone
Centrifugal Heat Dissipation YES Rotor Balance ≤5 mg
Propeller Mounting Holes D:12 M3×4,  18 M3×4,  22 M3×4 Motor Balance ≤10 mg
Shaft Diameter IN: 12 mm Motor Mounting Holes D:25 M3×4, D:30 M4×4
Bearing 6801ZZ*2 Disruptive test 500 V

___________________________________________________________________________________________________________________________

Drawing and mount holes
