FS 2004 DYNAMO FPV Drone motor

SKU: 0101DJ1624
The FS series of MAD FPV brushless motors is designed for freestyle flying. The development process involved six months of rigorous testing, resulting in refined aesthetics and functionality.
The main difference between the FS and BSC series is the superior quality of the materials used.
1. titanium shaft;
2. 0.15mm silicon steel sheet;
3.High temperature magnets;
4.Secondary anodizing.
$0.00 $14.00
Received successfully
Coupon Code
CONTINUE SHOPPING
    Please select the information you want X
  • KV OPTION:
    2950KV
    3500KV
    Rotors + locking shaft screw + O ring + Gaskets
  • Color:
    Red
    Green
    Please select the information you wantX
Quantity
-
+
Download
  • MAD DYNAMO FS2004 Brushless drone for freefly fpv drone
  • MAD DYNAMO FS2004 Brushless drone for freefly fpv drone
  • MAD DYNAMO FS2004 Brushless drone for freefly fpv drone
  • MAD DYNAMO FS2004 Brushless drone for freefly fpv drone
  • MAD DYNAMO FS2004 Brushless drone for freefly fpv drone
  • MAD DYNAMO FS2004 Brushless drone for freefly fpv drone
  • Description
  • 2950KV-6S
  • 3500KV-6S

Motor Data


Motor Model
MAD Dynamo FS2004 V1.0
Motor Number of slots
12N14P
Motor Size
D:24.3 × 17.25 mm
Rotor Balance
≤5 mg
Propeller Mounting Holes
D:5 M2X2   D:6 M2X2
Motor Balance
D:12 M2×4
Shaft Diameter
IN: 1.5 mm Cable Length
130 mm 24# Awg(Black) silicone

___________________________________________________________________________________________________________________________


Drawing and mount holes
